6A–42 ENGINE MECHANICAL
3. Install the camshaft with gear to the cylinder head.
Refer to “Camshaft Installation” in this manual.
4. Install the camshaft bearing caps.
5. Install the bridge caps.
1. Apply engine oil to the bridge cap.
2. Install the bridge cap to the bridge,
6. Install the rocker arm assembly.
Refer to “Rocker Arm Assembly Installation” in this
manual.
014EY00060
011MV009-1
011MX042
014MX016
To Next Page
