Single Phase Voltage Regulator RAV-2
with control CTR-2
Instruction Manual MI-010
Page: 18/27
Rev. 06/2017
Table 7: Adjustable parameters sequence
S. Shortcut Name Description Un. Range Increment Default Settings Remote Local
01 01
RTPC
VT relation for control - 25.0 a 300.0 0,1 Plate
1
display Adjust
02 02
RTCC
CT relation for control - 250 a 6000 1 Plate
2
display Adjust
03 03
VREFM1
Reference voltage map1 V 90 a 135 0,1 120 Adjust Adjust
04 04
INSM1
Bandwidth map 1 V 0,5 a 6,0 0,1 3 Adjust Adjust
05 05
TMPM1
Timer map 1 s 10 a 180 1 30 Adjust Adjust
06 06
DVQLRM1
Drop of resistive voltage on the line map 1 V -25 a +25 1 0 Adjust Adjust
07 07
DVQLXM1
Drop of reactive voltage on the line map 1 V -25 a +25 1 0 Adjust Adjust
08 08
VREFM2
Reference voltage map 2 V 90 a 135 0,1 120 Adjust Adjust
09 09
INSM2
Bandwidth map 2 V 0,5 a 6,0 0,1 3 Adjust Adjust
10 10
TMPM2
Timer map 2 s 10 a 180 1 30 Adjust Adjust
11 11
DVQLRM2
Drop of resistive voltage on the line map 2 V -25 a +25 1 0 Adjust Adjust
12 12
DVQLXM2
Drop of reactive voltage on the line map 2 V -25 a +25 1 0 Adjust Adjust
13 13
SEMIM2
Week to initiate the term of map 2 - 0 a 8 1 0 Adjust Adjust
14 14
HRIM2
Hour to initiate the term of map 2 - 0 a 23 1 0 Adjust Adjust
15 15
MINIM2
Minute to initiate the term of map 2 - 0 a 59 1 0 Adjust Adjust
16 16
SEMFM2
Week to end the term of map 2 - 0 a 8 1 0 Adjust Adjust
17 17
HRFM2
Hour to end the term of map 2 - 0 a 23 1 0 Adjust Adjust
18 18
MINFM2
Minute to end the term of map 2 - 0 a 59 1 0 Adjust Adjust
19 19
VREFM3
Reference tension map 3 V 90 a 135 0,1 120 Adjust Adjust
20 20
INSM3
Bandwidth map 3 V 0,5 a 6,0 0,1 3 Adjust Adjust
21 21
TMPM3
Timer map 3 s 10 a 180 1 30 Adjust Adjust
22 22
DVQLRM3
Drop of resistive voltage on the line map 3 V -25 a +25 1 0 Adjust Adjust
23 23
DVQLXM3
Drop of reactive voltage on the line map 3 V -25 a +25 1 0 Adjust Adjust
24 24
MESIM3
Month to initiate the term of map 3 - 0 a 12 1 0 Adjust Adjust
25 25
SEMIM3
Week to initiate the term of map 3 - 0 a 8 1 0 Adjust Adjust
26 26
HRIM3
Hour to initiate the term of map 3 - 0 a 23 1 0 Adjust Adjust
27 27
MINIM3
Minute to initiate the term of map 3 - 0 a 59 1 0 Adjust Adjust
28 28
QMESM3
Amount of months of map 3`s term - 0 a 12 1 0 Adjust Adjust
29 29
SEMFM3
Week to end the term of map 3 - 0 a 7 1 0 Adjust Adjust
30 30
HRFM3
Hour to end the term of map 3 - 0 a 23 1 0 Adjust Adjust
31 31
MINFM3
Minute to end the term of map 3 - 0 a 59 1 0 Adjust Adjust
32 32
VREFFI
Reference voltage inverse flow V 90 a 135 0,1 120 Adjust Adjust
33 33
INSFI
Bandwidth inverse flow V 0,5 a 6,0 0,1 3 Adjust Adjust
34 34
TMPFI
Timer inverse flow s 0 a 180 1 30 Adjust Adjust
35 35
DVQLRFI
Drop of resistive voltage on the inverse flow line V -25 a +25 1 0 Adjust Adjust
36 36
DVQLXFI
Drop of reactive voltage on the inverse flow line V -25 a +25 1 0 Adjust Adjust
37 37
MODABL
Automatic load bonus - 0 a 1 1 0 Adjust Adjust
38 38
BMAX
Maximum position block - 8 a 16 1 16 Adjust Adjust
39 39
BMIN
Minimum position block - -8 a -16 -1 -16 Adjust Adjust
40 40
LVMIN
Minimum voltage limiter V 1 a 15 1 15 Adjust Adjust
41 41
LVMAX
Maximum voltage limiter V 1 a 15 1 15 Adjust Adjust
42 42
BSC
Excess current block - 0.5 a 2.1 0,1 2 Adjust Adjust
43 43
MAFI
Actuation mode in case of inverse flow - 0 a 8 1 0 Adjust Adjust
44 44
TAC
Type of performance on the commutator - 0 a 5 1 2 display Adjust
45 45
MLPCOM
Tap changer position reading method - 0 a 3 1 0 display Adjust
46 46
DEFVC
Phase shift between voltage and current - 0 a 2 1 0 display Adjust
47 47
OPMEDF
Option of source voltage measurement - 0 a 1 1 0 display Adjust
1 For spare controls or reset to default the value is 115.
2 For spare controls or reset to default the value is 1000.
