ITech IT6018B-1500-40 - It6015 B-80-450

Technical Specification
Parameter IT6010B-80-300
Readback stability-
8h (％of Output
+Offset)
Voltage
≤0.02% + 0.02%FS
Current ≤0.1% + 0.1%FS
Input impedance
quiescent current
<7mA at Vmax
Efficiency
～90%
Remote Sense
Compensation
Voltage
≤5V
Command Re-
sponse Time
2ms
Storage
Temperature
-10℃～70℃
Protective Function
OVP, OCP, OPP, UVP, OTP, Vsense protect
Standard Interface
Standard: USB, CAN, LAN, VCP,
optional: GPIB, RS232
Isolation (input to
ground)
500V
Working
Temperature
0～50℃
Dimension ( mm) 483mm(W)*801.61mm(D)*151.3mm(H)
Weight( net)
30KG
7.1.3 IT6015B-80-450
Source Mode
Parameter IT6015B-80-450
Rated value
Output Voltage
0～80V
( 0 ℃-50 ℃) Output Current
-450～450A
Output Power
-15～15kW
Output Resistance
0～0.178Ω
Line Regulation Voltage
≤0.01%FS
±(％of Output+Offset)
Current ≤0.05%FS
Load Regulation Voltage
≤0.02%FS
±(％of Output+Offset)
Current ≤0.05%FS
