ITech IT7324 User Manual

Quick start
Copyright © Itech Electronics Co., Ltd. 9
Chapter2 Quick start
This chapter introduces the front panel, the rear panel, key functions and VFD
display function of the power supply, make sure that you can quickly know the
appearance, instruction and the key function before you operate the power
supply, Help you make better use of this series of power supply.
2.1 Brief Introduction
IT7300 Series is a kind of single-phase programmable AC power supply. It can
analog various normal and abnormal AC inputs, and measure a series of
important parameters of DUT. IT7300 Series power supply has following
standard communication interfaces: LAN, USB, GPIB (except IT7321) and
RS232. With combined features of both desktop and systematic power supplies,
it can deliver multi-purpose solutions based on design and test requirements.
Main features and advantages are listed below:
 Vacuum fluorescent display (VFD)
 LED display of panel function keys
 Adjustable set values by knob
 Output is switch control
 Display Vrms,Irms,Ipeak,frequency,PF,apparent power and active
power simultaneously
 Programmable frequency:45HZ-500HZ
 Turn on,turn off phase angle control(0-360°)
 Auto current measurement range
 Analog surge/trapped wave
 Support front and rear panel output
 High accuracy and resolution
 Memory capacity:10 groups
 Over-voltage,over-power,over-current,over-temperature protection
features
 Smart temperature-control fan with low noise
 Support 3-phase AC power supply function when 3 units are
connected together via System Bus
 Standard communication interface LAN,USB,RS232,GPIB
 Software monitoring via computer
Model Voltage Current Power
IT7321 300V 3A 300VA
IT7322 300V 6A 750VA
IT7322H
500V 3A 750VA
IT7324 300V 12A 1500VA
IT7324H 500V 6A 1500VA
IT7326 300V 24A 3000VA
IT7326H 500V 12A 3000VA
*IT7321 has no 3-phase AC power supply function and GPIB interface.

ITech IT7324 Specifications

General

Brand	ITech
Model	IT7324
Category	Power Supply
Language	English
