Remote Control
Copyright © Itech Electronics Co., Ltd. 50
device is DT1 enabled
5.3 LAN Interface
Press (Shift) + (Menu) on the front panel together to access the
menu. Select LAN in the Communication from System and then configure
Gateway, IP, Mask and SocketPort in the LAN option.
Connect the LAN interface of power supply to the computer with a reticle
(crossed).
5.4 GPIB Interface
Use a IEEE488 bus to connect GPIB interfaces of power supply and PC.
Please ensure that the screws have been screwed down in order to have a full
connection. Then press + (Menu) to enter the system menu to set
the address. The address range of power supply is 0-31.After you set the
address, please press button to confirm, GPIB address is saved in
nonvolatile memory.
