Chapter3 Function and Features
This chapter introduce the basic operations of IT7300 series AC
sourece.including the following subdivisions:
 Local/remote mode
 Voltage setup
 Frequency setup
 Phase angle setup
 Output on/off operation
 Switch the VFD display items
 Save/recall operation
 Trigger operation
 Menu operation
 Switch output voltage range
 Key lock function
 BNC terminals function
 3-phase AC power supply function
3.1 Switching of local/remote operation modes
Press the local button to change the AC source from remote to local
operation.After you power on the AC source, it defaults in local mode, all
buttons are enabled. While in remote mode, most buttons are disabled except
Shift and Local keys.In addition, the mode modificaton will not effect the output
parameters.
3.2 Voltage Setup
You can set voltage within the range of rated voltage value. When you press
button, the button will be lit. This indicates that you can set voltage.
There are three ways to set output voltage through front panel.
 The first way: press , adjust cursor location through button,
pressing and will enable you to adjust the setting voltage value.
 The second way: press , adjust cursor location through
button, adjust rotary knob to change the setting
voltage value.
 The third way: press button and numeric key( to ) to
set voltage value.
3.3 Frequency Setup
You can set frequency within the range 45Hz to 500Hz. When you press
, the button will be lit. This indicates that you can set frequency.There
are three ways to set frequency through front panel.
V-setV-set
0
9
