ITech IT7324 User Manual

Function and Features
Copyright © Itech Electronics Co., Ltd. 22
Irms-Protect
Current RMS protect point
Irms-Protect=12.000A
Set current RMS protect point
Delay
Irms protection will
be triggered in 1s
Immediate
Protection will be
triggered
immediately.
BNC-Set BNC PORT SETUP
I-Trigger
Input interface for external trigger
I-Ri
Input interface for on/off control
O-Sync
Output interface for AC phase
synchronization signal
O-On
Output interface for on/off state interface
Ipeak-Protect
Current peak protect point
Ipeak-Protect=12.000A
Set Current peak protect point
Delay
Irms protection will
be triggered in 1s
Immediate
Protection will be
triggered
immediately.
Dimmer
DIMMER
Phase dimmer
LeadingEdge
LeadingEdge Phase dimmer function
TrailingEdge
TrailingEdge Phase dimmer function
Off
Disable Phase dimmer function
List-Set
LIST START MODE
List start mode
On/Off
Press On/Off to start/stop running
Trigger
Press Shift + Enter (Trigger) to start/stop
running
3ø-Setup
A-Phase/ B-Phase /
C-Phase
Set the power supply to A-Phase, B-Phase
or C-Phase of AC power supply, with
difference of 120 degrees between any two
phases.
Disable/Enable
Turn on or turn off three-phase output
function.
To achieve this function,user need to
combine three units.
Meas- Curr-mode
Auto
Select automatic current measurement
mode
Manual
Select manual current measurement mode
High
Select high-range
current
measurement
Middle
Select mid-range
measurement
Low
Select low-range
measurement
Info
PRODUCT INFO:
Power information
ERROR INFO: For look up error information
PRODUCT INFO:
IT73XX
Ver:0.01~0.01
Instrument type/Firmware version
PRODUCT SN:
XXXXXXXXXX
XXXXXXXX
Instrument SN
RECORD INFO: Record information
