ITech IT7324 - IT7322 Specifications

Specification
Copyright © Itech Electronics Co., Ltd. 37
Resolution
0.1V
Accuracy
±(0.2%+0.6V)
Temp. coefficient
±(0.04% per degree from 25℃)
Current(rms)
Range
L:120.0mA *
M:1.200A *
H:3.00A *
Resolution
L:0.1mA
M:1mA
H:10mA
Accuracy
L:±(0.2%+0.6mA)
M:±(0.2%+6mA)
H:±(0.2%+40mA)
Temp. coefficient
±(0.04% per degree from 25℃)
Current(peak)
Range
0-12A
Resolution
0.01A
Accuracy
±(1%+0.36A)
Temp. coefficient
±(0.05% per degree from 25℃)
Power
Resolution
L:0.01W
M:0.1W
H:1W
Accuracy
L:±(0.2%+0.2W) (47HZ-65HZ)
M:±(0.2%+2W) (47HZ-65HZ)
H:±(0.2%+4W) (47HZ-65HZ)
Temp. coefficient
±(0.05% per degree from 25℃)
GENERAL
Memory 10 memories
Sync Output Signal Output Signal 5V,BNC type
Interface(Option) LAN,USB,RS232
Operation Environment
0-40
℃
/20-80%RH
Dimension
1/2
19" 2U
Weight
10Kg
Model IT7322
INPUT
Phase 1
Voltage
220Vac±10% or 110Vac±10%
Frequency 47-63Hz
Max.Current 15A(220Vac) or 30A(110Vac)
Power Factor 0.7(typical)
AC OUTPUT
