Romet cable number 34-125-43
Cable pin ERT module wire
Corrected Aux CC Alarm
F Red
Romet cable number 34-125-44
Cable pin ERT module wire
Aux CC
A
B
C White and blue
D Red
E
F
Romet cable number 34-125-45
Cable pin ERT module wire
Corrected Uncorrected Alarm
A White and blue
B Red
C White and blue
D Red
E White and blue
F Red
Romet cable number 34-125-50
Cable pin ERT module wire
Corrected Uncorrected Alarm
1 Red
2 White and blue
3 White and blue
4 Red
5 Red
6 White and blue
Romet cable number 34-125-51
Cable pin ERT module wire
Correct Uncorrected Aux CC
1 Red
2 White and blue
3 White and blue
4 Red
5 Red
Specific Meter Manufacturer Installation
100G Series Gas ERT Module Installation Guide, Remote Mount TDC-0824-017 59
Proprietary and Confidential
