Romet ECM2® meter wiring
The pulse weight for the volumetric outputs is configured in SetUp Mode at Menu items > SET
UNC OUT and Menu items > SET COR OUT. Since Setup Mode is fully configurable, the ECM2
®
module is universally adaptable to all Romet TC meter bodies. Reference the Romet technical
manual for specific details on the ECM2
®
.
Romet cable number 34-125-20
Cable pin ERT module wire
Corrected Uncorrected Alarm
A White and blue
B Red Red
C White and blue
D Red
E White and blue
Romet cable number 34-125-40 or 34-125-41
Cable pin ERT module wire
Corrected Uncorrected Alarm
A White and blue
B Red
C White and blue
D Red
E White and blue
F Red
Romet cable number 34-125-42
Cable pin ERT module wire
Corrected Uncorrected Alarm
A White and blue
B Red
C White and blue
D Red
E White and blue
F Red
Romet cable number 34-125-43
Cable pin ERT module wire
Corrected Aux CC Alarm
A White and blue
B Red
C White and blue
D Red
E White and blue
Specific Meter Manufacturer Installation
100G Series Gas ERT Module Installation Guide, Remote Mount TDC-0824-017 58
Proprietary and Confidential
