For 500W ERT pit boxes, the type of installation method is based on the location of the meter in
the pit box and the lid material. Itron recommends mounting the pit module in pit boxes with in
plastic lids (or other composite materials) for optimum network performance. Metal lids require a
through-lid remote antenna and rod or wall mount accessory for optimal pit module radio
performance. The pit modules are temperature rated from -20° C to +60° C. Do not install the pit
module in locations that may exceed the temperature rating.
Warning
While Itron modules are designed to withstand a drop, dropping the module may damage the
device and void the warranty.
Pit module positioning other than upright will negatively affect radio performance.
Internal circuit card components are sensitive to electrostatic discharge. Be careful not to touch
any part of the meter body, register housing, or Riva module prior to discharging any static
buildup on your person. To discharge yourself, touch a grounded metal object such as the metal
water pipe or an earth-grounded metal structure.
Pit module mounting accessories
Accessory Part number
Remote antenna kit (required for rod and wall mount
installations)
CFG-0900-003
Riva 500W ERT module rod mount adapter CFG-1601-002
Fiberglass mounting rod. (Minimum order quantity is 100.)
12" OEM-1006-001
18" OEM-1006-002
36" OEM-1006-003
Riva 500W ERT module pit lid mounting kit CFG-1601-001
Cable armor (seeUsing the Itron Cable Armorfor field retrofit installation instructions)
5 foot cable thin-insulation (with protective cap and
cable armor)
CFG-0151-006SS
5 foot cable thick-insulation (with protective cap and
cable armor)
CFG-0151-010SS
5 foot cable armor for field retrofit FAB-1302-001
Pit module universal environmental cap MSC-0019-011
Itron security seal MSC-0018-001
08 January 2020 815-0006-01 Itron, Inc. Page 23 of 48
Template 4 Installing the OpenWay Riva 500W ERT Pit Module
