2. From the bottom side of the lid, screw on the threaded retainer clip collar until the beveled
top rests against the pit lid.
Note: Ensure that the beveled edge of the clip collar is toward the top of the pit lid.
3. Align and insert the retainer clip tab (1) into the retainer clip receptacle (2) on the pit module
housing.
Verify that the clip locks into place and the retainer clip collar is hand-tightened against the pit lid.
Caution: Carefully align the pit module through lid assembly. If the assembly is
improperly aligned, the pit lid may not close.
08 January 2020 815-0006-01 Itron, Inc. Page 26 of 48
Template 4 Installing the OpenWay Riva 500W ERT Pit Module
