IVIEW CyberPad 754TPC User Manual

3
Short Press ESC button will return to the last interface, long Press ESC
button will return to the main interface.
1.3 ESC
1.5 Earphone jack
1.6 Card Reader
1.7 Micro SD Card
1.8 USB
1.9 Reset
The buttons Volume +/Volume located on the side of the tablet which allow to
adjust volume.
1.4 Volume +, Volume-
3.5 mm standard earphone jack.
V
ideo output interface.
Card Reader Slot: External micro SD card.
USB jack: you can use it to connect the computer for data transmission,
charging and external connection USB flash drive.
In the case of sof tware breakdown, l ong press the power button f or
5 seconds to reset the tablet sysetm.
NOTE: It is not recommended to use the RESET key of ten since the
table
system may be damaged.

IVIEW CyberPad 754TPC Specifications

General

Processor model	Cortex-A8
Processor family	ARM
Processor frequency	1.2 GHz
Processor architecture	ARM Cortex-A8
Internal memory	0.5 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Internal storage capacity	4 GB
LED backlight	-
Display diagonal	7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Maximum video resolution	- pixels
Main camera resolution (numeric)	0.3 MP
Speaker power	1 W
Number of built-in speakers	1
Docking connector	No
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g
Top Wi-Fi standard	802.11g
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Google applications	Google Play
Form factor	Slate
Product color	Black, White
Operating system version	4.0
Operating system installed	Android
Battery capacity	2800 mAh
Battery life (max)	- h
Cables included	USB
Graphics card	Mali 400

Weight and Dimensions

Depth	7.6 mm
Width	120 mm
Height	190 mm
Weight	317 g
Package depth	71.12 mm
Package width	140 mm
Package height	216 mm
Package weight	861 g
