IVIEW CyberPad 754TPC User Manual

• ••• •••••• •
1. Appearance and button
2
Earphone jack
Touch panel
Speaker
Power
Front camera
back camera
Esc
Menu
DC 5V
USB
MIC
Card Reader
7”
1.1 Touch panel
Capacitive touch panel: During the operation, you can click and drag
items on the touch panel.
1.2 POWER
To power on: Press and hold the power button, the system will enter the main
interface.
To power off: In the main menu interface, press the power button for about 5
seconds to power off, the system will appear "power off" option, click “ok’’ and
you can safely power off.
Lock screen: Press power button to lock screen or unlock screen.
: When the power ran out, the system will power off automatically.
【Remark】

IVIEW CyberPad 754TPC Specifications

General

Processor model	Cortex-A8
Processor family	ARM
Processor frequency	1.2 GHz
Processor architecture	ARM Cortex-A8
Internal memory	0.5 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Internal storage capacity	4 GB
LED backlight	-
Display diagonal	7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Maximum video resolution	- pixels
Main camera resolution (numeric)	0.3 MP
Speaker power	1 W
Number of built-in speakers	1
Docking connector	No
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g
Top Wi-Fi standard	802.11g
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Google applications	Google Play
Form factor	Slate
Product color	Black, White
Operating system version	4.0
Operating system installed	Android
Battery capacity	2800 mAh
Battery life (max)	- h
Cables included	USB
Graphics card	Mali 400

Weight and Dimensions

Depth	7.6 mm
Width	120 mm
Height	190 mm
Weight	317 g
Package depth	71.12 mm
Package width	140 mm
Package height	216 mm
Package weight	861 g
