CHAPTER 7 SPECIFICAITONS
1. VIDEO
Input Level
1.0 Vp-p±10% Composite, 75 Balanced
Display Speed
NTSC
120fps(4CH)
PAL
100fps(4CH)
Display Resolution
NTSC
720(H) X 480(V)
PAL
704(H) X 576(V)
Monitor Output
2Vp-p Composite, 75 Balanced
2. RECORDING
Compression Method
H.264
Recording Speed
Refer to table 7-1
Recording Resolution
NTSC
720 X 480, 720 X 240, 360 X 240
PAL
704 X 576, 704 X 288, 352 X 288
Quality
Independent for
each channel
Below Basic/ Basic/ Normal/ High/ Highest
Schedule
Setup by minute as unit
Mode
Manual / Event (Motion, Sensor) / Schedule
Method
By resolution, fps and quality
Setup fps and quality separately for normal and
event recording
3. SATA DEVICE
Capacity
Internal Storage
1 HDD
External Storage
Not support
Type
SATA / SATA compatible
4. ALARM
Sensor Input
4(4CH)
Loop Out
1 Relay out
Motion Detection
Available per each camera/ Multi-detection level
5. CONNECTIONS
Video Input
4 ports (4CH)
Video Output
BNC 2 port, VGA 1 port
Audio Input
RCA 4 CH
Audio Output
RCA 1 CH
USB 2.0
USB memory stick, USB Touch Panel
USB 1.1
USB Mouse
Remote
Remote control
External I/O
1 RS-485, 4(4CH) sensor input, 1 Relay Output
Ethernet
1 RJ45 connector, 10/100 Mbps
6. ELECTRICAL
Power Source
DC 12V / 3A
7. ENVIRONMENTAL
Operation Temperature
5 ~ + 40
Humidity
Less than 90%
