Ivoclar Vivadent Programat EP 5000 - Page 7

7
Control unit:
70 Program key
71 ESC key
72 ENTER key
73 START key
74 Start LED
75 STOP key
76 + key
77 - key
78 Settings / information
79 Cursor key up
80 Cursor key down
90 Open furnace head
91 Close furnace head
92 Numeric keys
93 Firing / Pressing
94 Home key
95 Help key
8
59
4
44
3
41
50
54
42
100 Programat firing tray
101 Metal pin A
102 Metal pin B
103 Metal pin C
115 Cooling grid
(complet)
110 USB data cable
100
115
101
103
102
120 Automatic Temperature
Control Set 2 – ATK 2
120
110
78
93
95
94
79
80
70
77
76
72 92
71
73
74
75
91
90
105 USB stick Programat
106 Protective cover
105
106
