MONITOR DESCRIPTION
Model 3000 Operation Manual
MONITOR DESCRIPTION
The Model 3000 series Cardiac Trigger Monitor is an easy to use color monitor that displays a patient’s ECG
waveform and heart rate. The ECG lead displayed can be selected from Leads I, II or III. In addition high and low
heart rate alarm limits can be adjusted to bracket the patient’s heart rate so that a violation of these limits produces
an audible and visual indication of the violation. The color display has a single trace, large Heart Rate numbers and
alphanumeric characters for other data, alarm messages, menus and user information.
The Model 3000 monitor is intended primarily for use on patients in applications requiring precision R-wave
synchronization such as timed imaging studies.
An optional integral recorder is available, set up of recorder functions are made through the monitor menus
The Model 3000 series are available with different options; not all options are included in all monitors.
The Model 3000 is suitable for use in presence of Electro-surgery.
The Model 3000 is not intended for use with any other physiological monitoring unit.
The Model 3000 is restricted to use on one patient at a time.
The Model 3000 is not intended for home-care patient monitoring
Classification (in accordance with IEC-60601-1)
Protection against electric shock: Class 1.
Degree of protection against electric shock: Type CF applied part. Defibrillator proof: ECG
Degree of protection against harmful ingress of water: Ordinary equipment IPX0 per IEC-60529
Methods of Maintenance and Cleaning: See page 30
Degree of safety of application in the presence of a Equipment not suitable for use in the presence of a
flammable anesthetic mixture with air or with oxygen flammable anesthetic mixture
or nitrous oxide:
Mode of operation: Continuous
