MONITOR SETUP
Model 3000 Operation Manual 17
To set the Trace Speed
Use the following procedure to change the trace speed.
1. Press the [SPEED] key in the main menu to select the trace speed. Selections are 25, and 50 mm/s.
NOTE: The [SPEED] key also changes the speed of the recorder.
Default Settings
To reset the monitor to the default settings, turn monitor off by pressing the STBY key; then press and hold the
fourth and fifth soft key (from left to right) while applying power to the monitor by pushing the ON key.
Setting
Initial Default
ECG Size
10mm/mv
Lead
II
AC Filter
ON
Pacer Detection
ON
Trigger*
Positive
Heart Rate Low Limit
60
Heart Rate High Limit
120
Speed
25mm/sec
Recorder
Direct
QRS Vol.
OFF
Alarm Vol.
High
Alarms
OFF
Some settings (see list below) are stored in non-volatile memory which means that the monitor powers up with the
same options that were in effect when power was last turned off.
Setting
Options
Speed
25mm/sec
50mm/sec
Recorder
Direct
Delay
Timed
Alarm Vol.
High
Low
Trigger*
Positive
Negative
*If the polarity control is not installed, the options for the Trigger pulse are only ON (Initial default) and OFF.
