RECORDER OPERATION
26 Model 3000 Operation Manual
Direct To print in direct, press the [PRINT] key. Press [PRINT] again to stop printing.
The plot is preceded by a header which contains all parameter readings and the time/date.
The speed of the plot and vertical resolution are the same as the display. The plot is labeled with the speed
of the plot in mm/s, the recorder mode, and the parameters.
Timed TIMED mode starts by pressing [PRINT] and prints for 30 seconds.
Delay Delay mode plots 30 or 40 seconds of ECG waveform after the occurrence of an alarm condition or if print
button is pushed depending on the speed selected:
15 seconds before and 15 seconds after at 50mm/s
20 seconds before and 20 seconds after at 25mm/s
Recorder Speed
Use the following procedure to change the recorder speed.
1. Press the [SPEED] key in the main menu to select the trace speed. Selections are 25, and 50 mm/s.
NOTE: The [SPEED] key also changes the speed of the ECG trace.
Example Printout
