ECG MONITORING
20 Model 3000 Operation Manual
Patient Connections
To ensure compliance with both safety and performance specifications, use the patient cables supplied by Ivy
Biomedical Systems (see Accessories). Other cables might not produce reliable results.
Use only high quality pre gel silver/silver-chloride electrodes or equivalent.
Use the following procedure for ECG monitoring:
1. Before applying the electrodes, use Nuprep gel or a gauze pad to gently clean the area where the electrodes will
be applied.
2. Connect the patient cable to the monitor's front panel ECG input.
3. Connect the leads to the patient cable.
4. Attach the leads to the electrodes.
5. Use the procedures described in the following sections for alarm limit settings, lead selection, amplitude
adjustment, and enabling or disabling the filter. See the menu diagram below.
ECG Waveform Amplitude (Size)
Use the following procedure to adjust the amplitude (size) of the displayed ECG waveform.
1. Press the [SETUP] key from the main menu. The following menu appears.
2. Press the first programmable key [ECG] once to select ECG.
HR(BPM)
