J.P. Instruments EDM-960

For Your Safe Flight Page | 45
ENABLE PRE-
ALARM MSGS
YES or NO
Tap YES or NO to enter gauges for
pre-alarm setting for , HI EGT, HI
TIT,HI CHT, HI OIL-T, HI MAP,
LOW TANK.
HI EGT = 1650
1250
1650 F
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
HI TIT =1650
1250
1650 F
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
HI CHT =450
260  460
F
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
HI OIL-T = 210
190  240
F
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
LOW OIL-T = 100
100  150
F
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
HI MAP = 30
30.0 
38.0
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
LOW TANK = 5
1  50 gal.
In gallons or preset value. Use
PLUS or MINUS to adjust. Tap
NEXT to skip to the next item.
AVERAGE CRUISE
RPM 2400
2043 
2563 rpm
Hold NEXT and button 2 until you
see ADJUST for two seconds.
Tap PLUS or MINUS to adjust.
Hold NEXT and button 2 to Save.
AMPS ADJUSTMENT
+ 0
-10  10
Use PLUS or MINUS to adjust.
Tap NEXT to skip to the next item.
Engine HP 210
10  999
HP
Hold NEXT and button 2 until you
see ADJUST for two seconds.
Tap PLUS or MINUS to adjust.
Hold NEXT and button 2 to Save.
