conMIG 300
Operating manual Page 31
After the job menu is open, it is possible to select the job number by rotating the left knob (MC 3). Now
there is the possibility to load a stored job by pressing the control key ‘LOAD’, or to store the actual
settings by pressing the control key ‘STORE’. To overwrite a used memory cell, press the ‘STORE’ key
for more then 1 second.
Deleting jobs / reset to factory settings (MC 3)
The control unit has 2 possibilities:
1. to delete all user jobs, display ‘rES 1 – Job’ or
2. to reset all values to factory settings, display ‘rES 2 – ALL’.
Press the key Fx until ‘EC 1’ appears in the display.
Now tip 3 times on key Fx until ‘rES 1 – Job’ in the display appears.
With the left control knob you can change between ‘rES 1 – Job’ or ‘rES 2 – ALL’.
Press the key ‘Gas test’ until the word ‘clr’ disappears in the right display.
The reset is finished.
Note: After the function reset ALL it is necessary to check all parameters of the unit, whether the
parameters have the right values !
Gas test (MC 3-5)
To open the gas valve, press the control key ‘gas test’ for more then 1 second. The gas valve is now
open for 20 seconds. After this time the gas valve closes automatically. To close the gas valve earlier,
press the control key again.
Wire feed in (MC 3-5)
In normal operation (not Job mode!) the wire-feed-in function will be activated by pressing the control
key ‘wire-feed’. The motor is running as long as the key is pressed. The speed can be adjusted by the
left rotating knob.
28. Material table
The following materials are standard in the control unit:
Material Display MC Gas Display MC Wire diameter / mm
Steel St Argon 82%, CO
2
18% - MIX 18 Ar82 0,8
Steel St Argon 82%, CO
2
18% - MIX 18 Ar82 1,0
Steel St Argon 82%, CO
2
18% - MIX 18 Ar82 1,2
Steel St Argon 90%, CO
2
5%, O2 5% Ar90 0,8
Steel St Argon 90%, CO
2
5%, O2 5% Ar90 1,0
Steel St Argon 90%, CO
2
5%, O2 5% Ar90 1,2
Steel St CO
2
Co2 0,8
Steel St CO
2
Co2 1,0
Steel St CO
2
Co2 1,2
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 0,8
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 1,0
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 1,2
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 0,8
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 1,0
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 1,2
ALMG 5 ALnG Argon 100% (Ar) Ar 1,0
ALMG 5 ALnG Argon 100% (Ar) Ar 1,2
ALSi 5 ALSi Argon 100% (Ar) Ar 1,0
ALSi 5 ALSi Argon 100% (Ar) Ar 1,2
