Jackle conMIG 445 - Material and Gas Settings Table

conMIG 400/445/545
Operating manual Page 42
To assign a function to a potentiometer, press Fx until ‘EC 1’ appears in the display.
Once more tipping on the key Fx to select EC 2. With the middle rotating knob, select the function as described
above (in the middle display).
Store the function by tipping on the key ‘wire-feed in’.
Note: In this type of machine the right display must show the word ‚CAn’
The values with the display ‘int’ do not work with this machine!
e.g.: EC1 - Choc - CAn
Now it is possible to change the value of the choc with potentiometer 1.
32. Material table
The following materials are standard in the control unit:
Material Display MC Gas Display MC Wire diameter / mm
Steel St
Argon 82%, CO
2
18% - MIX
18
Ar82 0,8
Steel St
Argon 82%, CO
2
18% - MIX
18
Ar82 1,0
Steel St
Argon 82%, CO
2
18% - MIX
18
Ar82 1,2
Steel St
Argon 82%, CO
2
18% - MIX
18
Ar82 1,6
Steel St Argon 90%, CO
2
5%, O
2
5% Ar90 0,8
Steel St Argon 90%, CO
2
5%, O
2
5% Ar90 1,0
Steel St Argon 90%, CO
2
5%, O
2
5% Ar90 1,2
Steel St Argon 90%, CO
2
5%, O
2
5% Ar90 1,6
Steel St CO
2
Co2 0,8
Steel St CO
2
Co2 1,0
Steel St CO
2
Co2 1,2
Steel St CO
2
Co2 1,6
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 0,8
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 1,0
CrNi 4316 – ER308 4316 Argon 98%, CO
2
2% - MIX 2 Ar98 1,2
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 0,8
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 1,0
CrNi 4576 4576 Argon 98%, CO
2
2% - MIX 2 Ar98 1,2
ALMG 5 ALnG Argon 100% (Ar) Ar 1,0
ALMG 5 ALnG Argon 100% (Ar) Ar 1,2
ALSi 5 ALSi Argon 100% (Ar) Ar 1,0
ALSi 5 ALSi Argon 100% (Ar) Ar 1,2
