ProTIG 220/300 AC/DC
Operating manual Page 51
Farbenlegende / Colour key:
Farbe
Colour
AN
Orange / Schwarz Orange / Black
Ar
Orange Orange
Az
Hellblau Sky - Blue
Bc
Weiß White
Bl
Blau Blue
BN
Weiß / Schwarz White / Black
Gg
Grau Grey
Gl
Gelb Yellow
GV
Gelb / Grün Yellow / Green
Mr
Braun Brown
Nr
Schwarz Black
Ro
Rosa Pink
Rs
Rot Red
Vd
Grün Green
Vi
Violett Violet
Übersicht Komponenten / overview components:
•1
•3
•4
•5
•6
•7
•8
•9
•10
•11
•12
•13
•14
•15
CA CP CR CT D DB DD DW ED EVG F FCTA FHF FPP
•16
•17
•18
•19
•20
•21
•22
•23
•25
•26
•27
•28
•29
•30
FPS HR IL L L1-2 M MI MV PF PSR6 PT RF RP S-
INV
•31
•32
•33
•34
•35
•36
•37
•38
•39
•40
•41
•42
SDF SF SHF SS TC TF TH THF TORCH TP UP W
Deutsch:
•1 Hilfsstecker 230V •3 Kondensatoren •4 Anschluss Kühlgerät •5 Anschlussbuchse Fernbedienungen
•6 Sekundär Dioden •7 IGBT Modul •8 Display •9 Taster ‚Down‘ •10 Encoder •11 Gasventil •12 Sicherung
•13 HF Filter Fernbedienung •14 HF Filter •15 Potentiometer Fußpedal •16 Schalter für Fußpedal
•17 Kühlgerät •18 Hauptschalter •19 Drossel •20 PFC Drossel •21 Wasserpumpe 230V •22 "Full Bridge"
IGBT Modul •23 Lüfter 230V •25 Diodenbrücke •26 Fußpedal •27 Brennertaster •28 Folientastatur
•29 Primärgleichrichter •30 Kontrollplatine •31 Bedienplatine •32 EMV Filter •33 Zündgerät •34 Sekundär
Platine •35 Stromwandler •36 Ferritkern •37 Sekundär Temperaturfühler •38 HF Übertrager •39 Brenner
•40 Haupttransformator •41 Taster ‚UP‘ •42 Wasserdruckschalter
English:
•1 Connector 230V •3 Capacitors •4 Cooling system connector •5 Remote control connector •6 Secondary
diode •7 IGBT module •8 Display •9 Button ‘Down’ •10 Encoder •11 Gas solenoid valve •12 Fuse •13 Torch
filter and accessories •14 HF filter •15 Pedal control potentiometer •16 Pedal control switch •17 Cooling
system •18 Supply switch •19 Inductor •20 PFC inductances •21 230V water pump •22 "FullBridge" IGBT
module •23 Fan 230V •25 Diodebridge •26 Pedal control •27 Torch trigger •28 Keyboard •29 Primary rectifier
•30 INVERTER board •31 Digital board for the front panel •32 EMC filterboard •33 HF unit •34 Secondary
circuit IGBT board •35 Current transformer •36 Ferrit core •37 Secondary circuit diode thermostat •38 HF
transformer •39 Torch •40 Main transformer •41 Button ‘Up’ •42 Pressure switch
