Jackson AJ-44 - D226 Steam Booster Dimensions

AJ-44C Series Technical Manual 7610-001-76-22
Issued: 03-21-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
D226 STEAM BOOSTER DIMENSIONS
26
16
6
16
16
13
11
NOTE: All dimensions are in inches and are
for reference only.
43
11
24
14 4
43”
11”
14”
4”
24”
11”
16”
16”
13”
6”
16”
