Jackson AVENGER HT-E - Wash & Drain Motor Assembly Parts List

43
RINSE MANIFOLD ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 Complete Rinse Arm Assembly 05700-004-01-56
1 2 Rinse Arm, Plugs 05700-004-05-23
2 1 Nozzle 04730-004-01-07
3 1 Washer, Rinse Arm 05330-011-42-10
4 1 Bearing, Rinse Arm 03120-004-12-13
5 1 Bushing, Rinse Head 05700-021-33-84
6 1 O-Ring, Silicon 05330-002-60-69
7 1 Rinse, Retaining, Rinse Head Bushing 05340-112-01-11
8 1 Rinse Hub 05700-004-03-77
8
2
3
6
7
3
1
5
4
