RINSE TANK ASSEMBLY

PARTS

ITEM QTY DESCRIPTION PART NUMBER

1 2 Booster Heater, 2kW 04540-003-98-38

1 ** 480V Unit Only 04540-004-13-30

2 2 Heater Gasket 05330-100-01-10

1 ** 480V Heater Gasket 05330-011-47-79

3 8 Lockwasher, Split 5/16" S/S N/A

4 8 Nut, Hex 5/16-18 S/S N/A

5 1 W-Booster 05700-004-04-16

1 ** 480V Booster 05700-004-13-25

6 2 Fitting, 1/4", 61HD-4 Brass Nut/Sleeve 05310-924-02-05

7 2 Probe, Temperature 06680-002-16-80

8 2 Insulation, Booster Tank Wrap 05700-004-09-57

** Models with 480V Control Box
