07610-003-92-84-Q
27
XL-E-LTH CONTROL BOX
PARTS
D
ITEM QTY DESCRIPTION PART NUMBER
XL-E-LTH Control Box Complete Assembly 05700-004-49-01
1 1 Box, Control Assembly 05700-004-49-02
2 1 Bracket, Terminal Block 05700-004-51-59
3 2 Bracket, Pressure Switch 05700-004-08-99
4 1 Bracket, Timer Mounting 05700-004-08-77
5 2 Chemical Feeder Pump Assembly, 36 RPM 05700-003-78-74
6 1 Chemical Feeder Pump Assembly, 14 RPM 05700-003-31-86
7 1 Timer, Wash Cycle Delay 05945-002-13-78
9a
To Next Page
