Jackson CONSERVER XL-E - Tub Assembly

07610-003-92-84-Q
46
ITEM QTY DESCRIPTION PART NUMBER
1
1 Tub Assembly, XL-E/XL-E-LTH 05700-003-78-39
1 Tub Assembly, XL HH 05700-004-27-28
2 1 Rack Guide Assembly 05700-031-36-76
3 1 Bulkhead Fitting, 1/2” 04730-011-45-21
4
1
1
Clamp, Nylon
Lock Nut, 10-24 SS
04730-011-39-01
05310-373-01-00
5 1 Wash Arm Assembly 05700-003-59-35
6
4
4
Bolt, 1/4-20 x 1/2” SS
Lock Nut, 1/4-20 SS
05305-274-02-00
05310-374-01-00
7
4
4
Bolt, 1/4-20 x 1 1/8” SS
Lock Nut, 1/4-20 SS
05305-274-21-00
05310-374-01-00
8 1 Lower Wash Manifold 05700-003-78-40
5
6
2
8
4
3
7
1
TUB ASSEMBLY
PARTS
