Jackson CONSERVER XL-E - Page 43

07610-003-92-84-Q
37
XL-E-LTH HOOD ASSEMBLY
PARTS
1 1 Control Box Assembly, XL-E-LTH 05700-004-49-01
2 1 Hood, Weldment 05700-004-08-68
3 1 Gasket, Air-gap 05330-002-14-48
4 1 Air-gap 05700-004-34-42
5 1 Nipple, 3/4" x 2" Brass 04730-207-46-00
6 2 Elbow, 3/4", 90-degree Brass 04730-206-13-00
7 1 Nipple, 3/4" x 1 3/8" Brass 04730-207-34-00
8 1 Solenoid Valve, 3/4”, 208/230 V 04810-100-03-18
9 1 Nipple, 3/4" x 4 1/2" Brass 04730-004-04-53
10 1 Y-Strainer, 3/4" NPT Brass 04730-717-02-06
11 1 Bracket, Plumbing Support 05700-004-48-11
12 6 Wear Button 05700-011-88-01
13 2 Bracket, Cantilever Support 09515-003-15-64
14 1 Bracket, Manifold Position Tube 05700-011-34-63
15 1 Locknut, 1/4-20 with Nylon Insert 05310-373-01-00
16 1 Coupling, 3/4" 04730-704-04-00
17 1 Nipple, 3/4" x 3” Brass 04730-011-38-29
18 10 Locknut, 10-24 with Nylon Insert 05310-374-01-00
19 12 Washer, SS 1/4” 05311-174-01-00
20 6 Bolt, 1/4-20 x 1/2” 05305-274-02-00
21 1 Manifold, Wash Feed 05700-003-58-89
22 2 Hood Support 05700-002-78-99
ITEM QTY DESCRIPTION PART NUMBER
