Jackson CONSERVER XL-E - Page 57

07610-003-92-84-Q
51
ITEM QTY DESCRIPTION PART NUMBER
Complete Booster Tank Assembly 05700-004-52-09
1 1 Booster Tank 05700-004-52-23
2 1 Plate, Booster Tank Base 05700-004-48-90
3 4 Bracket, Booster Mount 05700-004-48-83
4 1 Bracket, Booster Tank 05700-004-52-08
5 2 Plumbing, Booster Inlet/Outlet 05700-004-52-28
6 1 Hose, Blue 3/4" x 45" 05700-004-52-27
7 1 Hose, Red 3/4" x 49" 05700-004-52-26
8 16 Washer, 1/4-20 05311-174-01-00
9 16 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
10 1 Cover, Booster Tank 05700-004-52-21
11 1 Decal, Warning-Disconnect Power 09905-100-75-93
12 6 Nut, Hex 5/16-18 05310-275-01-00
13 6 Lockwasher, Split, 5/16" 05311-275-01-00
14
14a
1
1
Heater, Rinse
Gasket, Rinse Heater
04540-121-47-40
05330-200-02-70
15
15a
1
1
Thermostat, High Limit
Bracket, High Limit Thermostat
05930-004-33-12
05700-004-36-84
16 1 Bracket, Booster Tank 05700-004-55-05
XL-E-LTH BOOSTER TANK ASSEMBLY
PARTS
