Jackson DELTA 115 - Electrical Requirements

4
07610-003-62-15-Q
All electrical ratings provided in this manual are for reference
only. Always refer to the machine data plate to get exact electrical
information for this machine. All electrical work performed on
machines should be done in accordance with applicable
local, state, territorial, and national codes. Work should only
be performed by qualied electricians and authorized service
agents.
Note that all electrical wiring used in the Delta
®
series of machines
must be rated, at a minimum, for 212 °F (100 °C), and that only
copper conductors must be used.
Where applicable, heating element amperage draws have been
adjusted for the assumed input voltage. The manufacturer
assumes incoming voltages will be either 208 or 230 Volts. Some
heating elements used in the machines could be rated for other
voltages, so always verify the amperage draw of the machine in
operation when sizing circuit protection.
If the dishmachine is equipped with an optional rinse heater, note
the rinse heater might have its own electrical connection and
require a separate service. Amperage loads for motors and heaters
are indicated on the machine data plate.
Delta
®
1200
Electrical Characteristics
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
VOLTS 208 230
PHASE 1 1
FREQ 60 60
WASH
MOTOR
AMPS
0.5 A 0.4 A
WASH
HEATER
AMPS
13.0 A 14.4 A
TOTAL
LOAD
13.5 A 14.8 A
NOTICE
i
Delta
®
115
Electrical Characteristics
VOLTS 115
PHASE 1
FREQ 60
WASH
MOTOR
AMPS
3.1 A
WASH
HEATER
AMPS
11.3 A
TOTAL
LOAD
14.4 A
