Jackson DELTA 115 - Specifications; Machine Dimensions

2
07610-003-62-15-Q
vertical dimensions
SECTION B-B
SECTION A-A
B B
A
A
Drain
12" VERTICAL
CLEARANCE
19.45"
29.26"
2.00" Wall Clearance
6.01"
Inlet
27.69"
25.66
12.86"
8.64"
14.64"
25.25"
5.00"
9.50"
25.00"
Water Inlet 1/2" I.P.S. Cold
Water Inlet 1/2" I.P.S. Hot
6.0
"
SIDE VIEW
FRONT VIEW
OVER VIEW
LEGEND
Scale = 0.09:1
A = Designates the machine’s rightmost side from the front
B = Designates the machine’s base
1-1/2” (38 mm)
Drainline Connection
*All dimensions are for reference only and are subject to change without notice.
MACHINE DIMENSIONS
SPECIFICATIONS
LEGEND
A - Designates the machine's rightmost side from the
front.
B- Designates the machine's base.
All dimensions from the oor can be increased 1 1/4" with
the machine's adjustable feet.
NPT
NPT
"
