Jackson DELTA 115 - Outer Shell Assembly

37
07610-003-62-15-Q
OUTER SHELL ASSEMBLY
PARTS
4
ITEM QTY DESCRIPTION PART NUMBER
1 1 Outer Cover 05700-003-57-95
2 1 Bushing 05975-210-03-00
3 1 Access Cover 05700-003-58-73
4 4 Bullet Foot 05340-108-01-03
5 1 Switch Cover 05700-003-60-39
6 1 Power Switch 05930-011-61-69
7 1 Curtain 08415-003-60-35
8 1 Jackson Decal 09905-004-03-02
9 1 Curtain Rod 05700-003-60-38
9
1
2
3
5
6
78
