Jackson DELTA 115 - Page 47

40
07610-003-62-15-Q
RINSE ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 2 Rinse Arm 05700-003-42-81
2 1 Top Manifold 09330-003-45-71
3 6 Rinse Arm End-cap 05700-003-55-57
4 2 Rinse Arm O-ring 05330-011-74-55
5 1 Bottom Manifold 09330-003-45-67
6 1 Bottom Manifold Inlet 04710-003-60-46
7 2 Elbow 04730-003-61-77
8 2 Elbow, 90-degree 1/4" x 1/4" 04730-111-48-87
9 2 Fitting, 3/8" NPT x 1/2" Barbed 04730-002-18-54
10 2 Cover, Solenoid Assembly 05975-111-62-70
11* 2
Solenoid Valve Delta 1200 04730-011-61-54
Solenoid Valve Delta 115 04730-002-75-48
12 2 3/8" Close Nipple 04730-002-18-00
13 2 Union, 3/8" NPT Straight Brass 04730-003-60-57
14 2 Tee, 3/8" x 3/8" x 3/8" MNPT 04730-011-61-53
15 2 Jam Nut 05310-011-61-45
16 1 Mounting Plate 05700-003-60-21
17 2 Coupling, 1/2" FNPT x 3/8" FNPT 04730-011-61-52
18 1 Check Valve, 3/8" FNPT 04820-011-61-56
19 1 Ball Valve, 3/8" FNPT 04820-011-61-58
20 2 Fitting, 1/4" MNPT 04730-011-61-62
21 1 Thermometer 06685-111-35-30
22 1 Injection Manifold 05700-031-60-37
23 1 Bracket 05700-003-58-80
24 1 Gauge 06685-011-64-29
25 1 Bottom Manifold Inlet 05700-003-60-45
