44
07610-003-62-15-Q
PARTS
CONVEYOR & DRIVE SYSTEM
ITEM QTY DESCRIPTION PART NUMBER
1 1 Cylinder 05700-003-49-10
2 1 Rack 09330-003-45-66
3 3 Guide Block 09330-003-51-17
4 1 Strainer Weldment 05700-003-59-93
5 1 Drain Defelctor, Wash 05700-003-48-99
6 1 Plate, Skid 09330-003-58-52
7 1 Drive Gear 09330-003-58-32
8 1 Washer 05330-003-41-75
9 1 Extension Spring 05340-003-41-83
10 1 Gear Motor Box 05700-003-48-87
11* 1
Gear Motor (Delta 1200) 06105-003-44-23
Gear Motor (Delta 115) 06105-004-26-30
12 1 Gear Motor Box Cover 05700-003-48-57
13 2 Lock Nut, 6-32 05310-373-03-00
14 1 Switch Mounting Bracket 05700-003-60-13
15 1 Liquidtite Fitting 05975-011-49-03
16 1 Limit Switch 05930-303-38-00
17 2 Limit Switch Mounting Screws 05305-171-10-00
18 1 Activator Weldment 05700-003-58-50
19 1 Limit Switch Actuator 05700-003-58-54
