en 48

6 OPERATION

WARNING

When the machine is being used, whether

cutting grass or not, on slopes, the ROPS

frame should be deployed and the seat belt

used. This rationale is based on the fact that

a seat belt must be worn with a ROPS to

comply with the Machiney Directive

2006/42/EC Sections 3.2.2, Seating & 3.4.3,

Rollover

Ransomes Jacobsen Limited recommends that

a local risk assessment is completed by the

owner/user of the machine to determine the risks

associated with working on slopes.
