Jacobsen Super LF 1880

91
> Change from previous revision
LF 1880
Item Part No. Qty. Description Serial Numbers/Notes
1
4119514 1 Frame, 18” Reel
2 1000997 1 • Decal, Groomer Warning
3 361877 2 • Decal, Danger
4 4119513 1 Reel, 11 Blade Used on 67932 Only
4 4119512 1 Reel, 8 Blade Used on 67933 Only
5 1000480 1 Housing, Bearing
6 336962 1 • Seal, Grease
7 500534 1 • Bearing, Cup and Cone
8 471214 1 • Grease Fitting, Straight
9 471242 1 • Fitting, 1-5 psi Relief
10 1004786 1 Housing, Bearing
11 336962 1 • Seal, Grease
12 500534 1 • Bearing, Cup and Cone
13 471216 1 • Grease Fitting, Straight
14 471242 1 • Fitting, 1-5 psi Relief
15 3010296 2 • Pin, Motor Mounting
16 444708 2 • Locknut, 1/4-20 Center
17 5002151 1 Spring, Compression
18 304745 1 Washer
19 364900 1 Nut, Reel
20 163892 1 Seal, Grease
21 367164 1 Spacer, 7/8 x 1-13/16”
22 453011 1 Flat Washer, 3/8
23 446142 1 Lockwasher, 3/8 Heavy
24 400294 1 Screw, 3/8-24 x 3/4” Hex Head
25 2000065 1 Casting, Counterweight
26 400110 2 Screw, 1/4-20 x 7/8” Hex Head
27 446130 2 Lockwasher, 1/4 Heavy
28 458013 1 Snap Ring
29 400192 8 Screw, 5/16-18 x 1-1/2” Hex Head
30 453009 4 Flat Washer, 5/16
31 445795 8 Nut, 5/16-18 Spiralock Flange
32 315298 2 Bolt, Wheel
33 2811055 1 Backing, Bedknife
34 4118902 1 Bedknife
35 3009138 11 Screw, 1/4-20 Special Flat Head
36 3001720 1 Coupler, Motor Included with Tractor
37 412503 4 Set Screw, 3/8-16 x 1-1/4” Sq Head
38 2810165 1 Clip, Motor
39 2810166 1 Clip, Motor
