MAINTENANCE & LUBRICATION CHARTS 6
GB-27
6.3 MAINTENANCE CHARTS ___________________________________________________
A - Add or Adjust C - Clean I - Inspect L- Lubricate R - Replace AR - As Required
* Indicates initial service for new machines.
** Or every two years whichever comes first.
*** Inspect visible hoses and tubes for leaks or oil marks.
I - Manual grease gun with NLGI Grade 2 (Service Class
LB).
II - Engine Oil - See Section 4.3
III - Use Textron Golf, Turf & Specialty Products
GreensCare 68 hydraulic fluid: Capacity: 8 gallons
(30 Liters). Order Part No. 5003102, containing 55 gal.
(208 liter) drum or Part No. 5003103 containing 5 gal.
(19 liters), pail.
IV - 50/50 water ethylene glycol mix
Recommended Service and Lubrication Intervals
Every
8-10
Hours
Every
50
Hours
Every
100
Hours
Every
200
Hours
Every
400
Hours
Every
500
Hours
Every
1000
Hours
Yearly See
Section
Lubricant
Type
Air Filter
IAR R4.4
Battery Charge
I-C 4.7
Belts
I-A* I-A R 3.2
Brake
I-A* A 3.7
Cooling System
I-C-A R** 4.18 IV
Electrical System
I I 4.12
Engine Oil
IR* R 4.3 II
Engine Oil Filter
R* R
Fuel System
I4.6
Fuel Filter
R4.6
Grease Fittings - All
LLL L 6.2 I
Hydraulic Hoses and Tubes
I*** I 4.10
Hydraulic Oil
I-A R** 4.11 III
Hydraulic Oil Filter
I R* R 4.11
Muffler and Exhaust
I I 4.13
Radiator Screens
I-C/AR 4.18
Tires
I I-A 4.14
