Page #140 background imageLoading...
Page #140 background image
112
A
B
P
T
.5 ci .5 ci .5 ci
3045 psi
1160 psi
3045 psi
58 psi
1.35 ci
.425 ci
3000
RPM
A
B
Gear
Pump
Front
Reel
Valve
L
R Reel Motor
R
R Reel Motor
R
F Reel Motor
C
Reel Motor
L
F Reel Motor
10
Micron
25 psi
Crack
Bypass
30 psi
Crack
Bypass
Return
Filter
Oil
Cooler
A
B
C
D
E
F
G
H
I
.60 ci
.60 ci
.60 ci
.60 ci
.60 ci
3000
psi
A
B
P
T
Rear
Reel
Valve
3000
psi
LF 1880
53.1 Hydraulic Schematic
Serial No. All
