111
LF 1880
SW3 See 38.1 3007392 Neutral Proximity Switch
SW4 See 15.1 363996 Water Temperature Switch
SW5 See 4.1 554390 Seat Switch
SW6 See 5.1 3006449 Reel Switch
SW7 See 37.1 3006447 Back Lap Switch
SW8 See 18.1 3007392 Reel Position Proximity Switch
SW9 See 5.1 3006436 4WD Switch 4WD Units Only
SW10 See 38.1 3007392 4WD Drop Out Proximity Switch 4WD Units Only
SW11 See 5.1 3006436 Light Switch
SW12 See 5.1 1004290 Joystick
SW13 See 5.1 3006447 Horn Switch
SW14 See 20.1 3001279 Float Switch
SW15 Not Shown 554018 Engine Oil Pressure Switch Included in Engine
U1 Not Shown N/S Alternator Included in Engine
U2 See 5.1 366670 Horn
U3 See 5.1 162723 Hour Meter
U4 See 5.1 162720 Temperature Gauge
U5 See 5.1 162721 Volt Meter
U6 See 37.1 4108560 5 Second Lift Delay Relay
U7 See 15.1 364501 Temperature Sender
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
To Next Page
