Jacobsen Super LF 1880 Parts & Maintenance Manual

110
LF 1880
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 365099 Battery
CB1 See 37.1 361439 50 Amp Circuit Breaker (Alternator)
D1 See 37.1 2811376 Diode Block (Interlock) Included in Main Harness
D2 See 37.1 2811376 Diode Block (Lift/Lower) Included in Main Harness
F1 See 37.1 5003278 5 Amp Fuse (Guages) Included in Main Harness
F2 See 37.1 5003282 20 Amp Fuse (Lights) Included in Main Harness
F3 See 37.1 5003280 10 Amp Fuse (Lift/Lower) Included in Main Harness
F4 See 37.1 5003278 5 A Fuse (4WD) Included in Main Harness
F5 See 37.1 5003284 30 Amp Fuse (Glow Plugs) Included in Main Harness
F6 See 37.1 5003280 10 Amp Fuse (Ignition Switch) Included in Main Harness
F7 See 37.1 5003284 20 Amp Fuse (Ignition Circuit) Included in Main Harness
K1 See 37.1 3001307 Glow Plug Relay
K2 See 37.1 3001307 Brake Relay
K3 See 37.1 3001307 Neutral Relay
K4 See 37.1 3009544 Seat Time Delay Relay
K5 See 15.1 2500867 Fuel Solenoid Included in Engine
K6 See 37.1 3001307 Reel REV Roatation Relay
K7 See 37.1 3001307 Reel FWD Rotation Relay
K8 See 37.1 3001307 Interlock Relay
K9 See 46.1 2812374 Front Reel Valve FWD Solenoid Included in Front Reel Valve
K10 See 46.1 2812374 Front Reel Valve REV Solenoid Included in Front Reel Valve
K11 See 46.1 2812374 Rear Reel Valve FWD Solenoid Included in Rear Reel Valve
K12 See 46.1 2812374 Rear Reel Valve REV Solenoid Included in Rear Reel Valve
K13 See 37.1 3001307 Lift Hold Relay
K14 See 37.1 3001307 Lift Relay
K15 See 47.1 2812374 Lift Solenoid Included in Lift Valve
K16 See 47.1 2812374 Lower Solenoid Included in Lift Valve
K17 See 37.1 3001307 Ignition Relay
K18 See 37.1 3001307 4WD Relay 4WD Units Only
K19 See 48.1 5002945 4WD Solenoid Included in 4WD Valve
K20 See 37.1 3001307 Start Relay
K21 See 37.1 3001307 Float Relay
K22 See 37.1 3001307 Horn Relay
L1 See 5.1 164194 Engine Oil Light
L2 See 5.1 366751 Parking Brake Light
L3 See 38.1 1004776 Work Light (Right Side)
L4 See 38.1 1004776 Work Light (Left Side)
L5 See 5.1 366751 Hydraulic Oil Warning Light
M1 Not Shown N/S Starter Motor Included in Engine
M2 See 38.1 1004465 Fuel Pump
R1 Not Shown 5000899 Glow Plugs Included in Engine
R2 See 38.1 558019 Alternator Resistor, 75 Ohm 1 Watt
SW1 See 5.1 2810269 Ignition Switch
SW2 See 7.1 3007392 Parking Brake Proximity Switch
