Jacobsen Super LF 1880

95
> Change from previous revision
2
3
5
6
7
8
9
10
11
4
1
Item Part No. Qty. Description Serial Numbers/Notes
1
3008593 1 Tube, Down Pressure
2 352435 1 Spacer
3 366974 1 Rod End
4 400268 1 Screw, 3/8-16 x 1-3/4” Hex Head
5 4113001 1 Spring, Down Pressure
6 443110 1 Nut, 3/8-16 Hex
7 443812 1 Nut, 3/8-24 Hex Jam
8 446142 1 Lockwasher, 3/8 Heavy
9 453017 1 Flat Washer, 1/2
10 460312 1 Hairpin
11 461397 1 Roll Pin, 1/4 x 1-1/4”
42.1 Down Pressure
Serial No. All
