105
> Change from previous revision
LF 1880
Item Part No. Qty. Description Serial Numbers/Notes
4119328 1 Shaft and Bearing Assembly
1 N/S 1 • Driveshaft with SAE Spline
2 N/S 1 • Bearing, Front Driveshaft
3 N/S 1 • Ring, Retaining
4 N/S 1 • Retainer, Seal
5 N/S 1 • Ring, Bearing Retaining
● 6 N/S 1 Seal, Shaft
4119336 1 Kit, Saddle Bearing
7 N/S 2 • Bearing, Saddle
8 4119331 1 Swashblock
4119335 1 Rotating Group Bearing Assembly
9 N/S 1 • Bearing, Cylinder Hydrodynamic
10 N/S 1 • • Pin, Roll
11 N/S 1 • Ring, Retainer
4119334 1 Rotating Group
12 N/S 1 • Retainer, Shoe
13 N/S 7 • Assembly, Piston and Shoe
14 N/S 1 • Ball, Fulcrum
15 N/S 1 • Spring, Shoe Retainer
16 N/S 1 • Barrel, Cylinder
4119332 1 Control Housing Assembly
17 N/S 4 • Screw, 1/4-20 x 1” Socket Head
● 18 N/S 1 • O-Ring
● 19 N/S 2 • O-Ring
20 N/S 2 • Plug, #2 HP
21 N/S 1 • Assemply, Arm and Pintle
22 N/S 1 • Housing, Control
● 23 N/S 1 • Gasket, Control Housing
24 N/S 1 • Pin, Control
● 25 N/S 2 • O-Ring
26 N/S 1 Main Case
27 N/S 1 • Plug, Access
● 28 N/S 1 • O-Ring
● Included in Seal Kit 4119333
To Next Page
