Jacobsen Super LF 1880

32
4WD
OPERATING INSTRUCTIONS
READ MANUAL THOROUGHLY FOR OPERATING AND SAFETY INSTRUCTIONS.
REPLACEMENT MANUAL AVAILABLE FROM: JACOBSEN/TEXTRON, RACINE WI.
TO START TO DRIVE TO USE IMPLEMENT TO STOP
1. Set Parking Brake.
2. Set Speed Control
treadle in neutral.
3. Place pto switch
in off position.
4. Set throttle at
half position
5. For cold starting,
hold glow switch
for max. five seconds,
release switch.
6. Turn ignition switch
to start position.
1. Release parking
brake.
2. Set throttle to
fast position.
3. Depress treadle
pedal for desired
ground speed.
1. Lower implement
to ground
2. Place pto switch
in on position.
3. Depress treadle
pedal for desired
ground speed
1. Set treadle pedal
in neutral position.
2. Place pto switch
in off position.
3. Set parking brake.
4. Set throttle to
slow position.
5. Turn ignition to
off position and
remove key.
1
2
3
4
5
6
7
8
9
10
11
12
13
13
15
16
17
18
19
20
21
14
2
2
23 / 24
25
LF 1880
2.2 Decals
Units with Green Stripe
Serial No. All
