37
> Change from previous revision
LF 1880
Item Part No. Qty. Description Serial Numbers/Notes
1
66170 1 Suspension, Mini
2 5002620 1 • Spring Kit
3 400186 1 • Screw, 5/16-18 x 7/8” Hex Head
4 446136 1 • Lockwasher, 5/16 Heavy
5 443106 1 • Nut, 5/16-18 Hex
6 554718 4 • Nut, Push
7 554717 2 • Shaft, Pivot
8 554715 1 • Knob, Spring Tension
9 554714 2 • Bumper, Rear Downstop
10 554720 4 • Bearing, Sleeve
11 554719 2 • Spring, Extension
12 444762 1 • Locknut, 3/8-16 Center
13 554716 1 • Hanger, Spring
14 452010 1 • Flat Washer, 7/16
15 400190 4 • Screw, 5/16-18 x 1-1/4” Hex Head
16 452006 4 • Flat Washer, 5/16
17 3001328 4 • Screw, 5/16-18 x 5/8” Washer Hd
18 66172 1 Seat
19 434011 2 • Screw, 1/4-20 x 5/8” Socket Head
20 446130 2 • Lockwasher, 1/4 Heavy
21 554390 1 • Switch, Seat (NO) REFERENCE SW5, See 52.1
22 163583 1 • Wire Harness
23 3003928 1 Pouch, Literature
24 3001328 2 Screw, 5/16-18 x 5/8” Washer Hd
To Next Page
