Jade 32J - Technical Data and Specifications

25
MARK76J0002 Rev 3
Technical Data
Electrical Specications
ProSun Jade 32
Jade 32
Power consumption rating: 17 Amp
Rated Voltage: 120V ~ 17A 60Hz
Rated Fuses: 20 amp 2-pole
Continuous Operation: Continuous operation for a
maximum of 20 minutes.
Classication: Type B Applied Parts
Ingress protection classication: IP20
Protection against electric shock: Class I ME Equipment
Noise level inside the device: 71
Noise level 1m away from the
device:
62
Load on the base plate: Max 250lbs or 113 Kg
Equipment Weight: Approx 300 lb or 136 kg
Operating Humidity: 30-75%
Ambient Operating temperature: 50 to 86 degrees Farenheit
10 to 30 degrees Celcius
Max. operating altitude (above sea
level):
<6500 ft (2000m)
Max surface temperature: 146.6 degrees Farenheit
63.7 degrees Celcius
Note: If operating this equipment
at altitudes above 6500 ft / 2000m
above sea level adaption may be
needed to get normal operation.
