Jade 32J - Assembly Steps and Parts

55
MARK76J0002 Rev 3
2 Security Plates
FAMS6012236
2 Combi Arms
FAMS6012171
1 Alan Wrench
ACCE1009552
Included Parts
Make sure all parts are included before you begin.
6 Combi Arm Screws
FASN1508828
4 Gas Shock Pivots
GASP9008435
4 Security Clips
GASP90008436
1 Plastic Front Skirt (optional)
bronze - CVPL 6012336
red - CVPL 6513606
white - CVPL 6525156
1 Gas Shock
4 Security Plate Screws
FASN1513151
2 Deco Shield Nuts
FASN3001132
2 Deco Shield Washers
FASN6001362
2 Deco Shield Screws (optional)
black
FASN5010879
