one when inputting the figures.
8) ZERO/ESC key Zeros the display (within 2% of max.capacity) or cancels Tare action.
Exit from the setting or without saving.
9)
/MR key Recalls and displays the total Accumulation data (weight, total count
and number of weightments ) and the first 10 records in details. Circle the choices
in the setting. Make the blinking spot shift leftwards when inputting the figures.
10) PRINT/LO key Press the key to print when printing manually is selected. Set the LO
value. Enable the blinking figure decrease one when inputting the figures.
11) TARE/
key Inputs the weight of the object on the weighing pan as a Tare value ;
Inputs the indicated value entered via the numeric keys as a pre-set Tare value ; cancel
tare action. Display rightwards the first 10 records in detail. Make the blinking spot
shift rightwards when inputting the figures.
4-3 Power Supply
Power supply
Please verify the local AC power source and switch the two-stage switch to the proper place
before plugging into the power outlet.
Alternative power supply
1) AC 110V/220V (AC±10%)
2) (6V/4A) internal rechargeable battery
Power Consumption
About 300mW (without backlight)
About 380 mW (with backlight)
Low battery warning
When “ ” appears in the upper left corner of the weight window, the battery power
requires recharging. The charge lamp turns green from red when the recharging is completed
(which takes about 8 hours). Disconnect the scale from power supply when it is fully charged.
A full charged battery can operate the scale for approximately 65 hrs with backlight, 80hrs
without backlight.
Note: Battery is to replaced only by an authorized service dealer .Risk of explosion can occur
if replaced with the wrong type or connected improperly
5. Setting Mode
5-1 Function Setting
1) Press G N/SET key while powering on
Or long press G N/SET key in the weighing mode to enter parameter setting.
To Next Page
