Comm Mode User must enable the function for data logger.
Normal – Default
Jain View
CDMA Comm – CDMA Communication
MODBUS RTU – MODBUS Communication
Select Comm User can use both cable RS-232 and RS-485 to for the communication.
Comm Info
RS-232C
1 . CONFIGURE
2 . HEADER
3 . FORMAT
4 . SEPERATOR
5 . LOG INTERVAL
6 . LOG TIME SYNC.
7 . LOG ENABLE
8 . COMM MODE
9 . SELECT COMM 1 . DISABLE
0 . COMM. INFO. 2 . ENABLE
LOG ENABLE
RS-232C
1 . CONFIGURE
2 . HEADER
3 . FORMAT
4 . SEPERATOR
5 . LOG INTERVAL
6 . LOG TIME SYNC.
7 . LOG ENABLE 1 . NORMAL
8 . COMM MODE 2 . Jain View
9 . SELECT COMM 3 . CDMA COMM
0 . COMM. INFO. 4 . MODBUS-RTU
COMM MODE
RS-232C
1 . CONFIGURE
2 . HEADER
3 . FORMAT
4 . SEPERATOR
5 . LOG INTERVAL
6 . LOG TIME SYNC.
7 . LOG ENABLE
8 . COMM MODE
9 . SELECT COMM 1 . RS232
0 . COMM. INFO. 2 . RS485
SELECT COMM
RS-232C COMM. INFO.
1 . CONFIGURE LOG: DISABLE
2 . HEADER BAUD: 9600
3 . FORMAT N-8-1
4 . SEPERATOR LINE FEED OFF
5 . LOG INTERVAL NET ID: 0
6 . LOG TIME SYNC. MODE: NORMAL
7 . LOG ENABLE PORT: RS232
8 . COMM MODE HDR: DEFAULT
9 . SELECT COMM FMT: HFTA
0 . COMM. INFO. SEP: COMMA
